Echo Sounder JFC-800/810

Echo Sounder JFC-800/810

Simple and hi-performance, dual frequency with all-in-one design

  • Advanced digital signal processing
  • 10.4-inch sunlight viewable display
  • Two models; standard and high sensitivity
  • Multi-language; English, Chinese, Korean, Thai, etc.
  • Store and recall favorite fishing hotspots
  • Combination of zoom ranges
  • Auto function; gain, shift and range
Category: Tag:

Description

All-in-one system

The JFC-800/810 all-in-one echo sounder utilizes a rugged 10.4-inch bonded and sunlight viewable display, offering advanced filtering capabilities using digital signal processing technology to ultimately provide a clear image and allow for deeper sounding at higher frequencies.


  • 10.4-inch sunlight viewable display
  • Advanced digital signal processing
  • Dual frequency 50/200 kHz
  • External monitor output
  • NMEA data in/output
  • Different sounds for fish or school of fish
  • Up to 10 images stored in internal memory
  • Displays approximate fish size
  • Automatic gain, shift and range
  • Stores favorite fishing hotspots

The superior clutter suppression and signal to noise ratio and faster update rates allow for excellent performance in shallow water, while it also detects fish close to the bottom at depths not seen before with these high frequency transducers. The affordable 1 kW echo sounder equals or exceeds the performance of conventional sounders with 3x the power output.

Transducers

The echo sounder is available in two models. The JFC-800 is the standard model and includes a cost effective transducer. The JFC-810 features a higher sensitivity transducer. The preferred transducer depends on target fish, fishing method, fishing area and usage. ,Stores favorite fishing hotspots

Auto function

No need for guessing with this echo sounder anymore. Even a novice operator can achieve professional results by letting the JFC-800/810 pick the most optimum settings for functions such as range, shift and time variable gain (TVG).

Spesification :

Spec

ModelJFC-800JFC-810
TransducerStandardHigh Sensivity
Outp ut power (RMS)1kW
Output frequency50kHz and 200kHz
Output methodSingle or Alternate
Display size and type10.4 inch color TFT LCD
Display resolution640 × 480 pixels (VGA)
Basic range2.5 to 2000 (m), 10 to 6000 (ft), 2.5 to 1100 (fm / l.fm) (8 ranges can be set to users choice)
Zoom range2.5 to 200 (m), 10 to 650 (ft), 2.5 to 150 (fm / l.fm)
Range unitm, ft, fm, l.fm
Shift step1m, 10m, 1/8, 1/4
Presentation modesHigh frequency, Low frequency, Dual frequency, Zoom image (Bottom lock, Bottom discrimination, Bottom zoom, Zoom,Bottom follow zoom), Nav mode, Vertical split, Horizontal split,A-scope can be displayed at all above modes
Presentation colors64 colors, 16 colors, 8 colors, Monochrome
Back ground colorsMarine blue, Blue, Black, White, Nighttime color, Other 5 colors
AlarmsBottom, Fish, Temperature*1, Speed*2, Arrival*3, XTE*3
Image speed9 steps & stop
FunctionsInterference rejection, Color rejection, VRM, Noise rejection, White line, Draft correct, Water temperature correct, Boat speed correct,Store image (10 images), Sona-Tone, Fishing Hot Spot, Event memory, Simple plotter, Panel illumination, Power reduction, External trigger, Fish information, Detection area display
LanguageChinese, English, French, Greek, Italian, Japanese, Korean, Spanish, Thai
Input data format and sentencesNMEA0183 Ver.1.5/2.0/3.0
GGA, GLL, HDT, MTW, MWV, RMC, VHW, VTG, ZDA
Output data format and sentencesNMEA0183 Ver.2.0 (DBT : Ver.1.5)
DBT, DPT, GGA, GLL, HDT, MTW, MWV, RMC, TLL, VHW, VTG, ZDA
NMEA input / output port(s)1
Power supply10.8 to 31.2VDC
Power consumption30W or less (24VDC)
Ambient conditionsOperating temperature :-15 to +55℃ Water protection:IPX5

*1 : Water temperature sensor, or enter the external water temperature data is required
(JFC-810 has a built-in water temperature sensor)
*2 : Requires speed data from Speed sensor or GPS sensor
*3 : Requires data from GPS sensor
